SMG Rapid-Edge 18G Gear Type Plate Beveling Machine
The SMG Rapid-Edge 18G Gear Type Plate Beveling Machine is designed to provide workers with high-quality and efficient results when it comes to work preparations. It is designed to work with a wide range of plate specifications. Steel Machinery Group is your premier supplier of Plate Beveling Machine in Australia. We offer top-quality brands and provide quality service for all your beveling needs.
$ 11,342.00 AUD
SMG-12D-GBM High-Efficiency Metal Plate Beveling Machine widely used in construction industry for weld preparation. Clamp thickness 6-30mm and bevel angle range 25-45degree adjustable with high efficiency at processing 1.5-2.6meters per min. It helps a lot in saving labours.
Two processing ways:
- Model 1: Cuttcatchestch the steel and lead into the machine to complete the job while processing small steel plates.
- Model 2: Machine will travel along the edge of steel and complete the job while processing large steel plates.
Specifications
| Model No. | SMG Rapid-Edge 18G Gear Type Plate Beveling Machine |
| Power Supply | AC 415V 50HZ |
| Total Power | 1500W |
| Motor Speed | 1450r/min |
| Feed Speed | 1.5-2.6metesr/min |
| Clamp Thickness | 6-30mm |
| Clamp Width | ＞75mm |
| Process Length | ＞70mm |
| Bevel Angle | 25-45 degree as customer’s requirement |
| Single Bevel Width | 12mm |
| Bevel Width | 0 – 18mm |
| Cutter Plate | φ 93mm |
| Cutter QTY | 1 PC |
| Worktable Height | 700mm |
| Travel Space | 800*800mm |
| Weight | N.W 155KGS G.W 195KGS |
| Weight with Car | N.W 236KGS G.W 285KGS |
Note: Standard Machine includes:
- 3 pcs cutter
- Tools in case
- Manual Operation
Features
- Available for material: Carbon steel, stainless steel, aluminium etc
- IE3 Standard motor at 400w
- Hight Efficiency can reach up to 1.5 – 2.6 meter /min
- Imported reduction gearbox for cold cutting and non-oxidation
- No Scrap Iron Splash, more safer
- Max bevel Width can reach up to 18mm
| Weight | 10.00 kg |
|---|
